T-Motor Velox V2306 V3.0 1500/1750/1950/2550KV FPV Drone Brushless Motor – 5″, 4-8S

$13.89

The T-Motor Velox V2306 V3.0 is a premium, lightweight brushless motor engineered to deliver buttery-smooth linear throttle response and surgical stick precision.

Upgraded with enhanced magnetic authority and robust impact resistance, it offers pilots an unmatched cost-to-performance ratio without sacrificing reliability.

Add to Cart
T-Motor Velox V2306 V3.0 1500/1750/1950/2550KV FPV Drone Brushless Motor - 5", 4-8S
T-Motor Velox V2306 V3.0 1500/1750/1950/2550KV FPV Drone Brushless Motor - 5", 4-8S
$13.89

Free worldwide shipping on all orders over $199

  • Licensed by top brands to ensure product quality
  • Hassle-free 60 days warranty
  • 30 days easy returns
  • U.S. customers: tax is Trump’s Tariffs (10%)
Guaranteed Safe Checkout

The T-Motor Velox V2306 V3.0 Brushless Motor sets a definitive benchmark for value-tier flight dynamics, bringing raw agility, cinematic smoothness, and rugged durability to modern 5-inch FPV platforms. Utilizing a refined 2306 stator architecture, this motor provides a flawlessly linear throttle curve that grants pilots microscopic control in tight proximity gaps and aggressive freestyle maneuvers. It successfully dampens low-frequency mid-throttle oscillations, allowing your quad to track flawlessly through sharp cornering and high-G dives.

Weighing just under 34g, the V3.0 features an upgraded structural bell housing that acts as an efficient heat sink, rapidly dissipating heat under sustained high-amp strain to preserve peak magnetic performance. Its robust steel internal shaft (4mm inner, 5mm outer prop shaft) and premium heavy-duty bearings ensure it withstands the harsh impacts of bando-bashing and racing crashes. With versatile KV options optimized for snappy 4S, standard 6S, or extreme 8S high-voltage layouts, the Velox V2306 V3.0 is the ultimate choice for filmmakers and racers demanding absolute fluidity and everyday reliability.

Package Includes

  • 1x T-Motor Velox V2306 V3.0 1500/1750/1950/2550KV Motor
  • 1x Motor Accessories

Additional information

Weight N/A
Dimensions 27.9 × 27.9 × 30.65 mm
Brand: No selection

T-Motor

Motor KV: No selection

1500, 1750, 1950, 2550

Specs

KV1500 Version

  • KV: 1500KV
  • Configuration: 12N14P
  • Shaft Diameter: IN: 4mm OUT: 5mm
  • Lead: 20# 150mm
  • Weight (Incl. Cable): 32.7g
  • Rated Voltage (Lipo): 8S
  • Idle Current (10V): 0.7A
  • Max. Power (60s): 1969.9W
  • Peak Current (60s): 34.5A

KV1750 Version

  • KV: 1750KV
  • Configuration: 12N14P
  • Shaft Diameter: IN: 4mm OUT: 5mm
  • Lead: 20# 150mm
  • Weight (Incl. Cable): 33.8g
  • Rated Voltage (Lipo): 6S
  • Idle Current (10V): 0.85A
  • Max. Power (60s): 820.7W
  • Peak Current (60s): 34.9A

KV1950 Version

  • KV: 1950KV
  • Configuration: 12N14P
  • Shaft Diameter: IN: 4mm OUT: 5mm
  • Lead: 20# 150mm
  • Weight (Incl. Cable): 33.7g
  • Rated Voltage (Lipo): 6S
  • Idle Current (10V): 1.3A
  • Max. Power (60s): 976W
  • Peak Current (60s): 41.7A

KV2550 Version

  • KV: 2550KV
  • Configuration: 12N14P
  • Shaft Diameter: IN: 4mm OUT: 5mm
  • Lead: 20# 150mm
  • Weight (Incl. Cable): 32.6g
  • Rated Voltage (Lipo): 4S
  • Idle Current (10V): 1.95A
  • Max. Power (60s): 533.7W
  • Peak Current (60s): 34.5A
