iFlight XING 2806.5 Cinelifter 1300/1800KV FPV Drone Brushless Motor 4-6S

$33.89

The iFlight XING 2806.5 Brushless Motor is engineered to power 7 to 8-inch long-range quads and Cinelifter rigs with high torque and exceptional flight efficiency.

Featuring a crash-resistant 7075 Unibell housing, N52H arc magnets, and Japanese NSK bearings, it delivers reliable punch and silky-smooth throttle response.

Add to Cart
iFlight XING 2806.5 Cinelifter 1300/1800KV FPV Drone Brushless Motor 4-6S
iFlight XING 2806.5 Cinelifter 1300/1800KV FPV Drone Brushless Motor 4-6S
$33.89

Free worldwide shipping on all orders over $199

  • Licensed by top brands to ensure product quality
  • Hassle-free 60 days warranty
  • 30 days easy returns
  • U.S. customers: tax is Trump’s Tariffs (10%)
Guaranteed Safe Checkout

Built for 7- to 8-inch long-range cruisers and cinematic rigs, the iFlight XING 2806.5 motor delivers the ideal balance of massive low-end torque and high thermal efficiency. Its 2806.5 stator dimension generates instant power to easily carry heavy GoPro or HD video setups and recover from steep mountain dives.

Constructed with a durable 7075 aluminum Unibell bell, a 4mm titanium alloy internal shaft, and N52H curved arc magnets, this motor maximizes magnetic flux while keeping operating temperatures low. Paired with smooth Japanese NSK 11x5x5 bearings and available in 1300KV and 1800KV, the XING 2806.5 is a battle-tested workhorse for long-distance FPV exploration and high-payload filming.

Package Includes

  • 1 x XING 2806.5 motor
  • 1 x M5 Flange Nut
  • 4 x M3*8 screws

Additional information

Weight N/A
Brand: No selection

iFlight

Motor KV: No selection

1300, 1800

Specs

  • Model: XING 2806.5 Motor
  • KV: 1300KV/1800KV
  • Weight: 54.3g/53.3g
  • Dimension: φ35.06*36.8mm
  • Interphase Resistance: 72.29mΩ/ 48.5mΩ
  • Input Volts: 24V
  • Peak Current: 48.33A/72.3A
  • Max Watt: 1132.9W/1681.0W
  • Mounting Holes: 19*19 φ3mm
  • Rotor Specifications: Unibell
  • Shaft Diameter: 5mm
  • Shaft Protruding Length: 15.5mm
  • Lead: 265mm/18AWG
  • Magnet: N52H Curved
  • Configuration: 12N14P
  • Bearing Type: NSK
  • Bearing Specification: φ11*φ5*5
  • Winding: Single-strand copper winding
