Top fpv motor from Rcinpower for racing and freestyle. Wasp Major V2 motor is characterized by high performance, durability and pleasing appearance. The motor has a stator of unique size – 22.6 mm in diameter and 6.6 mm in height.

The motor has large round magnets for maximum performance. The base of the motor is reinforced, which increases the mechanical resistance of the motor. The motor have 3 colors Gray/Purple, Gunmetal/Gold, and Champion. 1980/2100/2160KV motor is perfect for 5-6S pilots that want a safe & ideal KV.

RCinpower Wasp Major 22.6-6.6 Motor Test Data

rcinpower wasp major v2 22 6 6 6 fpv brushless motor 1980kv test data chart
rcinpower wasp major v2 22 6 6 6 fpv brushless motor 2100kv test data chart
rcinpower wasp major v2 22 6 6 6 fpv brushless motor 2160kv test data chart

Package Includes

  • 1x RCinpower Wasp Major V2 22.6-6.6 1980/2100/2160KV Motor
  • 1x Motor Accessories

Additional information

Weight 32.2 g
Brand: No selection

RCinpower
Color: No selection

Champion Edition, Gunmetal/Gold, Purple/Gray
Motor KV: No selection

1980, 2100, 2160

Specs

Wasp Major V2 22.6-6.6 1980KV

  • KV: 1980
  • Configu-ration: 12N14P
  • Stator Diamter: 22.6mm
  • Stator Length: 6.6mm
  • Shaft Diameter: 4mm (Hollow)
  • Motor Dimension (Dia.*Len): Φ 27.6*18.1mm
  • Weight (g): 29.5 (3cm Wire)
  • Idle current (10)@10V(A): 1.2
  • No.of Cells (Lipo): 5~6S
  • Max Continuous Power (W) 5S: 1337
  • Internal Resistance: 56mΩ
  • Max Current (5S): 55.7A
  • Max Efficiency Current: (4-8A)>87%

Wasp Major V2 22.6-6.6 2100KV

  • KV: 2100
  • Configu-ration: 12N14P
  • Stator Diamter: 22.6mm
  • Stator Length: 6.6mm
  • Shaft Diameter: 4mm (Hollow)
  • Motor Dimension (Dia.*Len): Φ 27.6*18.1mm
  • Weight (g): 29.5 (3cm Wire)
  • Idle current (10)@10V(A): 1.3
  • No.of Cells (Lipo): 5~6S
  • Max Continuous Power (W) 5S: 1531
  • Internal Resistance: 52mΩ
  • Max Current (5S): 63.8A
  • Max Efficiency Current: (5-9A)>87%

Wasp Major V2 22.6-6.6 2160KV

  • KV: 2160
  • Configu-ration: 12N14P
  • Stator Diamter: 22.6mm
  • Stator Length: 6.6mm
  • Shaft Diameter: 4mm (Hollow)
  • Motor Dimension (Dia.*Len): Φ 27.6*18.1mm
  • Weight (g): 29.5 (3cm Wire)
  • Idle current (10)@10V(A): 1.4
  • No.of Cells (Lipo): 5~6S
  • Max Continuous Power (W) 5S: 1613
  • Internal Resistance: 48mΩ
  • Max Current (5S): 67.2A
  • Max Efficiency Current: (5-9A)>87%
